TLSense N305L2 MiniNAS: 2x 2.5Gbit LAN, N305 CPU, 32GB RAM, No SSD

Processor system
CPU	Intel® Core™ i3-N355 Processor
AES-NI	Supported
Graphics card	Intel® UHD Graphics
Graphics ports	1x DP, 1x HDMI
Memory type	DDR5 4800MHz. Up to 32G
Memory slots	1

Network
Ethernet ports	4
Ethernet speed	2.5Gbps
Ethernet chipset	Intel I226v

Storage
Primary storage	NVMe SSD. Up to 1TB (2x slots)
2nd storage	2.5'' SATA

Serial connection
Serial port	not present
This model doesn't have a serial port. Use the HDMI port to enter BIOS if needed.

External ports
External I/O	1x HDMI2.0, 1x DP1.4, 4x i226-V 2.5G LAN, 6x USB, 1x TF card slot, 1x DC-IN

Internal I/O ports
Internal I/O	2x M.2 NVMe SSD 1x 2.5''SATA3.0 SSD

Power
CPU TDP	15W
Idle draw	10.70W
Draw at 1 core	18.40W
Stress test draw	29.9W
Power Adapter	12V

OS Support
Supported operating systems	OPNSense, OpenWRT and many other router systems are supported

Mechanical
Chassis	Aluminium
Dimensions	160 x 125 x 51 mm
Mounting option	VESA mount (can be used to mount to a wall). Not included.
Cooling	Passively cooled. Fan is possible, but not included.

BIOS
BIOS	AMI BIOS

Warranty
Warranty	24 months

Other
Manufacturer	Tptn
gross weight	1.700
